NDAA Compliant
NDAA Compliant
Yes
General
Technology
Hybrid DVR
Recording Modes
Schedule, Manual, Motion, Sensor, Analytics, POS
Format
“All in 1” Hybrid (AHD / CVI / TVI / CVBS + IP)
Video Input
Video Input (Max Analog)
16CH Standard BNC + 8CH IP (Over Network)
Video Input (Max IP)
16CH IP (Over Network) + 8CH Standard BNC
3K Input Support
Yes
Video Output
Video Output
HDMI(4K, 1920x1080), VGA (1280x1024), CVBS(Spot)
Dual Output
Mirrored
Audio
Audio-In
8CH RCA (2.0 Vp-p, 1 kΩ) (+IP Cameras)
Audio-Out
1CH RCA (2.0 Vp-p, 1 kΩ) (+IP Cameras)
Audio Over Coax
Yes (TVI Only)
Two Way Audio
Yes
Audio Compression
G.711u
Events and Analytics
SMD Support
Yes
DDA Analytics (On Analog Channels)
Yes
Pixel Based Analytics
Yes
Main Resolution and FPS
IP Main Stream
8MP and lower: 25/30FPS Per Channel
AHD
8MP: Up to 8FPS Per Channel, 8MP Lite / 3K/5MP / 4MP: Up to 12/15FPS Per Channel, 5MP Lite: Up to 20FPS Per Channel, 4MP Lite / 2MP / 1MP: Up to 25/30FPS Per Channel
TVI
8MP: Up to 8FPS Per Channel, 8MP Lite / 3K/5MP / 4MP: Up to 12/15FPS Per Channel, 5MP Lite: Up to 20FPS Per Channel, 4MP Lite / 2MP / 1MP: Up to 25/30FPS Per Channel
CVI
8MP: Up to 8FPS Per Channel, 4MP: Up to 12/15FPS Per Channel, 2MP / 1MP: Up to 25/30FPS Per Channel
CVBS Main Stream
CVBS: 960H: Up to 25/30FPS Per Channel
Master Stream Over Network
8Ch
Network (Substream) Resolution and FPS
HD Analog
1-25/30FPS@1080P Per Channel (FPS Restricted to Master Stream FPS)
IP Sub Stream
1-25/30FPS@D1 Per Channel
CVBS Sub Stream
1-25/30FPS@D1 Per Channel
Substreams over Network
120 (Outgoing bandwith limit applies)
Remote view
Max Channel View
120Ch (Limited to Outgoing Bandwidth Capacity)
Video Compression
Video Compression
H.265 (HEVC) / H.264
Record
Recording Mode
Dual Stream
Remote Applications
User Access
5 Users Online with Professional Autorithy Management
Mobile App
Provision Cam2 for iOS/Android
PC/Mac Software
Ossia VMS Standard / Enterprise
Plug-in free Web-Browser
Chrome, FireFox, Safari, Edge, Opera. (All Limited to 4Ch Live View / Playback)
Plug-in based Web-Browser
Internet Exporer
Bandwidth
Incoming
32Mbps
Outgoing
96Mbps
Playback
Local Playback Channels
16Ch
Remote Playback Channels
8Ch
Search Modes
Time-Slice, Time, Event, File Management, Smart Search
Backup
USB
2 USB 2.0 Port
Backup Format
AVI/DAT
Alarm
Alarm-in
16+IPC
Alarm-out
4+IPC
Alarm Box Support
Yes
Storage
HDD Max Capacity
10TB
Total HDD Max Capacity
30TB
Number of HDD
2
E-Sata
1
PTZ
Connection
RS-485 / CoC / IP over Network
Supported Protocols
Pelco D, Pelco P, Samsung, Visca, ONVIF, CoC
Supported Controls
Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus
Network
Ethernet
1000 Mbps (RJ-45)
Protocols
TCP/IP, DHCP, DDNS, NTP, SMTP, RTSP, HTTPS, FTP, SNMP, P2P, POS
ONVIF
Yes (For IP Channels)
Others
Dimensions
W375xD275xH45mm
Power Supply
DC12V/4A
Operation Temperature
0°C ~50°C
