3rd Party Cyber Protection
General
Quantum IoT Nano agent by Check Point™
Protection Methods
Shell injection protection, File Monitor, Import-Table Protection, Dynamic-Memory Protection
NDAA Compliant
NDAA Compliant
Yes
Video
Video Input
16Ch over Network
Output
HDMI (4K@60Hz, 4K@30Hz, 1080P), VGA (1080P, 1280x1024, 1024x768)
View Mode
Mirrored
Fish-Eye Dewarp
Local + Web
Decoding Format
H.265 / H.265+ / H.265S / H.264
Decoding Capabilities
1Ch – 12MP ; 4Ch – 4MP ; 9-16Ch – D1
Audio
Audio-specs-Input
1CH RCA (Linear, 1kΩ) + IPC inputs
audio-specs-Output
1CH RCA (2.0 Vp-p, 1 kΩ) + IPC outputs IP Speaker
Compression
G.711A/G.711U
Two Way Audio
Yes
Analytics
Supported Analytics
Camera Tampering, DDA2 With Object Classification, Line Crossing (DDA / Pixel Based), Sterile Area (DDA / Pixel Based), Object Monitoring, Loitering Detection, Illegal Parking, Audio Exception, Heat Map, Object Counting (Line),Object Counting (Area), Smart Search, Face Recognition, LPR, Thermal, Crowd Gathering, People Intrusion Advanced Face Recognition Mode: Supports 2 Non-AI IPCs and performs face detection and recognition.
Analytics Channels (IPC Based)
16Ch (Requires supporting IPC)
Analytic Channels (NVR Based)
Up to 2Ch DDA1 (Sterile Area/Line Crossing) or Up to 2Ch Face Detection + Recognition or Up to 6Ch Face Recognition (IPC does Detection) (or their combinations)
Face Recognition Rate
18 Faces per second (6Ch supported)
Bandwidth
Incoming
160Mbps
Outgoing
160Mbps
Record/ Main Stream
Real-Time Recording
16CH 12MP Real-Time
Record Type
Video / Video + Audio
Recording Modes
Schedule, Manual, Motion, Sensor, Analytics, POS and all of its combinations
16MP
N/A
12MP
480FPS(NTSC)/400FPS(PAL)
8MP
480FPS(NTSC)/400FPS(PAL)
5MP and lower
480FPS(NTSC)/400FPS(PAL)
Master stream over network
Up to 12CH@Recording Resolution
Substream
Resolution substream
Depends on IPC
Remote view
Max Channel View
80Ch (Limited to Outgoing Bandwidth Capacity)
Remote Applications
User Access
64 Users online with Professional Autorithy Management
Mobile App
Provision Cam2 for iOS/Android
PC/Mac Software
Ossia VMS Standard / Enterprise
Plug-in free Web-Browser
Chrome, FireFox, Safari, Edge, Opera. (All Limited to 4Ch Live View / Playback) *P2P WEB connetion always requires Plugin
Plug-in based Web-Browser
Internet Exporer
Playback
Local
16Ch
Remote
16Ch
Search Mode
DDA Object, Smart Search, LPR, Face Recognition, Time-Slice, Time, Event, POS
Backup
USB
2 USB 2.0 Port + 1 USB 3.0 Port
Backup Format
AVI (Unencrypted) / Private Format (Encrypted / Unencrypted)
Alarm
Alarm-in
8+IPC
Alarm-out
4+IPC
Storage
HDD
2
HDD Max Capacity
10TB
E-Sata Support
No
Total HDD Max Capacity
20TB
RAID
N/A
PTZ
Connection
via Network
Supported Controls
Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus
RS-485
Yes (C06 Keyboard Connection)
Network
Ethernet
2x1000/100/10Mbps self-adaptive Ethernet interface with Fault Tolerance / Dual Network Configuration
Protocols
TCP/IPv4/IPv6, DHCP, DDNS, NTP, SMTP, SSL/TLS, UPnP, P2P, RTSP, FTP, HTTPS, 820.1X, SNMP, Auto Report Input + Output (Ossia VMS)
ONVIF
Full Device Support (Profile T/G, ONVIF Version 20.12)
PoE
PoE Ports
N/A
Speed
N/A
Standard
N/A
CCTV Mode
N/A
Total Power
N/A
Max. Power Output (Per Ch.)
N/A
Others
Power Supply
12VDC/4A
Power consumption (No HDD)
20W
Dimension
380 × 268 × 48.1 mm
Operation Temperature
0°C~50°C
