3rd Party Cyber Protection
General
Quantum IoT Nano agent by Check Point™
Protection Methods
Shell injection protection, File Monitor, Import-Table Protection, Dynamic-Memory Protection
NDAA Compliant
NDAA Compliant
Yes
Video
Video Input
64Ch Over Network
Output
HDMI1 (8K 30/60Hz, 4K, 1080P, 1280x1024) (When the resolution of HDMI1 output is 8K, HDMI2 is unavailable) HDMI2: 4K, 1080P, 1280×1024, 1024×768 HDMI3: 4K, 1080P, 1280×1024, 1024×768 HDMI4: 1080P, 1280×1024, 1024×768 VGA: 1080P 1280×1024, 1024×768 (VGA and HDMI1 output the same video source)
View Mode
Independent*, Up to 32ch Per Monitor (When enabled, NVR based analytics are disabled)
Fish-Eye Dewarp
Local + Web
Decoding Format
H.265 / H.265+ / H.265S / H.264
Decoding Capabilities
1Ch – 16MP ; 4Ch – 12MP ; 9/16Ch – 1MP ; 32Ch – D1 ; 64Ch – D1
Audio
Audio-specs-Input
1CH RCA (Linear, 1kΩ) + IPC Inputs
audio-specs-Output
1CH RCA (2.0 Vp-p, 1 kΩ) + IPC Outputs
Compression
G.711A/G.711U
Two Way Audio
Yes
Analytics
Supported Analytics
Camera Tampering, DDA2 With Object Classification, Line Crossing (DDA / Pixel Based), Sterile Area (DDA / Pixel Based), Object Monitoring, Object Counting (DDA), Crowd Gathering, People Intrusion, Smart Search, Face Recognition (Up to 16 CH), LPR, Thermal (Limited Support). Advanced Face Recognition Mode: Supports 4 Non-AI IPCs and performs face detection and recognition.
Analytics Channels (IPC Based)
64Ch (Requires supporting IPC)
Analytic Channels (NVR Based)
Up to 8Ch DDA1 (Sterile Area/Line Crossing) or Up to 4Ch Face Detection + Recognition or Up to 16Ch Face Recognition (or their combinations)
Face Recognition Rate
36 Faces per second (16Ch supported)
Bandwidth
Incoming
640Mbps
Outgoing
640Mbps
Record/ Main Stream
Real-Time Recording
64CH 16MP Real-Time
Record Type
Video / Video + Audio
Recording Modes
Schedule, Manual, Motion, Sensor, Analytics, POS and all of its combinations
16MP
1920FPS(NTSC)/1600FPS(PAL)
12MP
1920FPS(NTSC)/1600FPS(PAL)
8MP
1920FPS(NTSC)/1600FPS(PAL)
5MP and lower
1920FPS(NTSC)/1600FPS(PAL)
Master stream over network
Up to 64CH@Recording Resolution
Substream
Resolution substream
Depends on IPC
Remote view
Max Channel View
320Ch (Limited to Outgoing Bandwidth Capacity)
Remote Applications
User Access
128 Users online with Professional Autorithy Management
Mobile App
Provision Cam2 for iOS/Android
PC/Mac Software
Ossia VMS Standard / Enterprise
Plug-in free Web-Browser
Chrome, FireFox, Safari, Edge, Opera. (All Limited to 4Ch Live View / Playback) *P2P WEB connetion always requires Plugin
Plug-in based Web-Browser
Internet Exporer
Playback
Local
16Ch
Remote
16Ch
Search Mode
DDA Object, Smart Search, LPR, Time-Slice, Time, Event, POS
Backup
USB
2 USB 2.0 Port + 1 USB 3.0 Port
Backup Format
AVI (Unencrypted) / Private Format (Encrypted / Unencrypted)
Alarm
Alarm-in
16+IPC
Alarm-out
4+IPC
Storage
HDD
8
HDD Max Capacity
10TB
E-Sata Support
2
Total HDD Max Capacity
100TB
RAID
Yes (0/1/5/6/10)
PTZ
Connection
Via Network
Supported Controls
Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus
RS-485
Yes (C06 Keyboard Connection)
Network
Ethernet
2x1000/100/10Mbps self-adaptive Ethernet interface with Fault Tolerance / Dual Network Configuration
Protocols
TCP/IPv4/IPv6, DHCP, DDNS, NTP, SMTP, SSL/TLS, UPnP, P2P, RTSP, FTP, HTTPS, 820.1X, SNMP, Auto Report (Ossia VMS)
ONVIF
Full Device Support (Profile T/G, ONVIF Version 20.12)
PoE
PoE Ports
N/A
Speed
N/A
Standard
N/A
CCTV Mode
N/A
Total Power
N/A
Max. Power Output (Per Ch.)
N/A
Others
Power Supply
AC100-240V
Power consumption (No HDD)
50W
Dimension
W436xD445xH90mm
Operation Temperature
0°C~50°C
