3rd Party Cyber Protection
General
N/A
Protection Methods
N/A
NDAA Compliant
NDAA Compliant
Yes
Video
Image Sensor
1 / 1.8" CMOS
Effective Pixels
2560 × 1440
Day & Night
24/7 Full-Color Day Mode
Min. Illumination
Day: 0.000625lux / Night: 0.003lux (@F1.0, AGC on) 0lux with Led on
Audio
Audio compression
G.711A/G.711U
Communication
Two-Way Audio
Image Settings
AWB, AGC Adjustable, Exposure Mode (Auto) Sharpness, Saturation, Brightness & Contrast Adjustable
Image Enhancement
True WDR (120dB), BLC, HLC, ROI
Noise Reduction
3D-DNR
Image Orientation
Mirror/Flip
Privacy Zone
Yes
Events and Analytics
Motion Detection
Yes
Analytics
General Analytics: Camera Tampering AI (Object Recognition): DDA Sterile Area, DDA Line Crossing
Detect
62 m (203 ft)
Recognize
12 m (39 ft)
Identify
6 m (19 ft)
PIR (Passive Infra Red)
PIR Angle
Horizontal: 82° Vertical: 50°
PIR Range
Up to 15m
Compression
Frame Rate
1-12 FPS
Video Compression
H.265 / H.264 / H.265+ / H.264+ / MJPEG (Sub-stream only)
Resolution
4MP / 2K / 3MP / 2MP / 1MP / D1 / QVGA / CIF
Multi-Stream
Master Stream: 4MP(2560x1440) / 3MP / 2MP / 1MP Substream: 1MP / D1 / CIF / QCIF Third Stream: D1 / CIF / QCIF (1~12fps)
Bit Rate
64Kbps ~ 7Mbps@H.265 / 64Kbps ~ 8Mbps@H.264
Encode Mode
VBR/CBR
Image Quality
Five levels under VBR; Free adjustment under CBR
Lens
Lens (Field of View)
3.6mm (92°)
Water Protection
Yes
Iris
Fixed Iris
Network
Wiegand
N/A
Remote Monitoring
IE Browsing (Plug-In required), Chrome/Edge/Safari/Firefox plug-in free browsing, Ossia VMS Software, Provision Cam2 Mobile App
User Access
Supports simultaneous monitoring of up to 3 users with multi-stream real-time transmission
Network Protocol
IPv4, IPv6, TCP, UDP, DHCP, NTP, DDNS, 802.1X, RTSP, Multicast, UPnP, Email, FTP, HTTPS, QoS, HTTP POST, Auto Report, P2P
ONVIF
Profile T/S/G
Ethernet
100Mbps
Mobile Communication
SIM Card Type
Micro Sim
Mobile Network Frequency
LTE-TDD: Band 38/39/40/41; LTE-FDD: Band 1/2/3/4/5/7/8/12/13/18/19/20/25/26/28 WCDMA: Band 1/5/8 GSM: Band 2/3/5/8
Connectivity
Network
RJ45
Power
DC Socket Solar panels
Analog Video Output
No
Audio Connectivity
Built-in Microphone and Speaker (101±3dB)
SD Card
Event/Schedule based Main/Substream recording (Up to 256GB)
Alarm
No
Housing
Illumination
2 High-Power White LED: Full power: 20m Low power: 10m Red/Blue Strobe lights
Protection Rate
Water Proof: IP67
Bracket
3-Axis Bracket Angle Adjustment: Pan: 0°~360°; Tilt:-60°~10°
Dimensions
85 x 610 x 620
Weight (gross)
16.9KG (without LFP battery); Approx. 20.65 KG (with LFP battery)
Hard Reset Button
Yes
PoE
No
Power Supply
Power Consumption: < 5W Lower Power Mode: 3.5 W (4G working) Power Supply: 12 VDC ± 25% 60 W ±2Watt On Solar panels
Battery
Battery Type: LFP battery (lithium iron phosphate battery) Capacity: 24Ah Battery Voltage: 12.8V Operating Temperature: Charging: -20 ℃ to 45 ℃ (-4 °F to 113 °F) Discharging: -20 ℃ to 60 ℃ (-4 °F to 140 °F) Battery Life: More than 2000 charging cycles
Work Environment
-30°C~60°C, ~95% Or less Humidity
