3rd Party Cyber Protection
General
N/A
Protection Methods
N/A
NDAA Compliant
NDAA Compliant
Yes
Video
Video Input
4Ch over Network / PoE direct connection
Output
HDMI / VGA (1080P, 1280x1024, 1024x768)
View Mode
Mirrored
Fish-Eye Dewarp
Web Only
Decoding Format
H.265 / H.265+ / H.265S / H.264
Decoding Capabilities
1Ch – 5MP ; 4Ch – 2MP
Audio
Audio-specs-Input
Based on IPC only
audio-specs-Output
Based on IPC only IP Speaker (only for speaking)
Compression
G.711A/G.711U
Two Way Audio
No
Analytics
Supported Analytics
Camera Tampering, DDA2 With Object Classification, Line Crossing (DDA / Pixel Based), Sterile Area (DDA / Pixel Based), Loitering Detection, Illegal Parking, Audio Exception, Heat Map, Object Counting (Line),Object Counting (Area), Crowd Gathering, People Intrusion,Object Monitoring, Smart Search, Thermal (Limited Support) *DDA Analytics Live Snapshots are not supported
Analytics Channels (IPC Based)
4Ch (Requires supporting IPC)
Analytic Channels (NVR Based)
N/A
Face Recognition Rate
N/A
Bandwidth
Incoming
40Mbps
Outgoing
64Mbps
Record/ Main Stream
Real-Time Recording
4CH 5MP Real-Time
Record Type
Video / Video + Audio
Recording Modes
Schedule, Manual, Motion, Sensor, Analytics, POS and all of its combinations
16MP
N/A
12MP
N/A
8MP
N/A
5MP and lower
120FPS(NTSC)/100FPS(PAL)
Master stream over network
Up to 4CH@Recording Resolution
Substream
Resolution substream
Depends on IPC
Remote view
Max Channel View
20Ch (Limited to Outgoing Bandwidth Capacity)
Remote Applications
User Access
64 Users online with Professional Autorithy Management
Mobile App
Provision Cam2 for iOS/Android
PC/Mac Software
Ossia VMS Standard / Enterprise
Plug-in free Web-Browser
Chrome, FireFox, Safari, Edge, Opera. (All Limited to 4Ch Live View / Playback) *P2P WEB connetion always requires Plugin
Plug-in based Web-Browser
Internet Exporer
Playback
Local
4Ch
Remote
4Ch
Search Mode
DDA Object, Smart Search, LPR, Time-Slice, Time, Event, POS
Backup
USB
2 USB 2.0 Port
Backup Format
AVI (Unencrypted) / Private Format (Encrypted / Unencrypted)
Alarm
Alarm-in
Based on IPC only
Alarm-out
Based on IPC only
Storage
HDD
1
HDD Max Capacity
6TB
E-Sata Support
No
Total HDD Max Capacity
6TB
RAID
N/A
PTZ
Connection
via Network
Supported Controls
Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus
RS-485
N/A
Network
Ethernet
10/100Mbps self-adaptive Ethernet interface
Protocols
TCP/IPv4/IPv6, DHCP, DDNS, NTP, SMTP, SSL/TLS, UPnP, P2P, RTSP, HTTPS, 820.1X, SNMP, Auto Report Input + Output (Ossia VMS)
ONVIF
Full Device Support (Profile T/G, ONVIF Version 20.12)
PoE
PoE Ports
4xRJ45
Speed
10/100Mbps (10Mbps Under CCTV Mode)
Standard
PoE (IEEE802.3AF/AT)
CCTV Mode
Yes (Up to 200m and 10Mbps bandwidth)
Total Power
40W (Average 10W per Channel)
Max. Power Output (Per Ch.)
~25.5W
Others
Power Supply
DC48V/1.36A
Power consumption (No HDD)
5W
Dimension
W255xD220xH45mm
Operation Temperature
0°C~50°C
